TECHTONGDA WRL series Emulsifying Machine WRL series high shear emulsifying machine is a kind of vertical mounted emulsifying equipment. Widely used in the decomposition, dissolution, dispersion, shearing and emulsification of petroleum, chemical industry, daily use chemical industry, textile industry, food industry and so on. The excellent multifunctional feature greatly improves the mixing efficiency compared with the pure mixing principle, and has a wide range of versatility and flexibility. Overview Product introduction: WRL series high shear emulsifying machine is suitable for homogenization, refinement and emulsification on various large and small reactors and ordinary containers. Small capacitemulsion can also be used for mobile lifting. How it works: Under the drive of the motor, the material is sucked into the rotor area from the bottom of the container by the rotor which rotates at high speed. Under the strong mixing effect, the material is forced to pass through the gap between the precisely matched stator and the rotor and then thrown out from the stator hole. Items include: 1 x TECHTONGDA Disperser Mixer 1 x User Manual Product Features: High Quality 304 Stainless Steel Lightweight & Simple Structure Energy-saving & High Efficient Easy to Assemble & Disassemble Easy to Clean Noise-Canceling Long Service Life Speed not adjustable Strive for perfection in every detail! Stainless steel body Machine body is made of 304 stainless steel, in line with GMP pharmaceutical standards. Stainless steel impeller High quality stainless steel impeller, corrosion resistance and not easy to deformation. Hardened shaft The shaft adopts quenching process, which not only improves the hardness of shaft, but also makes it more resistant to corrosion and oxidation. Polished pump head With detachable and no dead Angle design, the polished pump head is easier to be cleaned to ensure that no liquid remains. Pure copper motor All models are equipped with pure copper motors to ensure long service life of the machines. Graphite sleeve Equipped with graphite shaft sleeve, alloy to graphite, make it durable and more efficient. Stainless steel rotor The rotor is made of high quality stainless steel, which is safe and pollution-free and provides a long service life. High quality bearing The special bearing not only reduces noise but also provides a higher speed. WRL-90 WRL-100 WRL-120 WRL-140 Buying Options Buying Options Buying Options Add to Cart Price — no data — no data — no data $1,345.00$1,345.00 Power: 1.5 KW 2.2 KW 4 KW 7.5 KW Voltage: Single-phase 220V Single-phase 220V 208/240V 208/240V Shaft length: 13.9" 25.6" 29.5" 35.4" Rated speed: 2800-2900 rpm 2800-2900 rpm 2800-2900 rpm 2800-2900 rpm Handling Capacity: 10~50L 50~100L 100~300L 300~800L Customizable sizes As a professional emulsifier manufacturer, we provide customized services. Please refer to the table for available models. Multiple installation mode Our emulsifier is designed with a universal flange interface and can be used in a variety of scenarios according to the user's requirements. For special needs, welcome to contakt us. We provide the 7*24 quick response. Note: the order does not include the bracket.
