14" - 26" Blade Capacity
| Maximum depth of cut with 14" blade: | 4-5/8" |
| Maximum depth of cut with 20" blade: | 7-3/8" |
| Maximum depth of cut with 26" blade: | 10-3/8" |
| Blade shaft RPM: | Varies |
| Blade shaft diameter: | 1-1/2" |
| Arbor size: | 1" w/drive pin |
| Blade shaft drive: | 4 belts up to 20.8HP, 5 belt for 25HP |
| Blade mounting: | Right or Left |
| Transmission (self-propelled only): | Eaton Model 6 |
| Drive Speed: | 0-130 feet/min |
| Fuel Capacity (gas models): | 5 gallons |
| Blade Capacity | Motor/Engine Power | Electric Start | Power Source | Engine/Motor Make/Model | Remote Cyclone Air Cleaner | Right or Left Hand | Part Number | Catalog Number |
|---|---|---|---|---|---|---|---|---|
| 14" | 15 HP, 230V-3PH | N/A | Electric | Leeson® | No | N/A | 5800400A | 48413 |
| 14" | 15 HP, 460V-3PH | N/A | Electric | Leeson® | No | N/A | 5800400B | 99980 |
| 20" | 15 HP, 230V-3PH | N/A | Electric | Leeson® | No | N/A | 5800401A | 98001 |
| 20" | 15 HP, 460V-3PH | N/A | Electric | Leeson® | No | N/A | 5800401B | 93694 |
| 26" | 15 HP, 230V-3PH | N/A | Electric | Leeson® | No | N/A | 5800402A | 94379 |
| 26" | 15 HP, 460V-3PH | N/A | Electric | Leeson® | No | N/A | 5800402B | 94409 |
| 14" | 20.8 HP, 35.6 torque (lbs.-ft.) | Yes | Gas | Honda® GX630 | Yes | N/A | 5800406 | 48418 |
| 20" | 20.8 HP, 35.6 torque (lbs.-ft.) | Yes | Gas | Honda® GX630 | Yes | N/A | 5800407 | 47164 |
| 26" | 22.1 HP, 35.6 Torque (lbs.-ft.) | Yes | Gas | Honda® GX630 | Yes | N/A | 5800408 | 48419 |
| 14" | 22.1 HP, 35.6 Torque (lbs.-ft.) | Yes | Gas | Honda® GX690 | Yes | N/A | 5801520 | 29637 |
| 20" | 22.1 HP, 35.6 Torque (lbs.-ft.) | Yes | Gas | Honda® GX690 | Yes | N/A | 5801521 | 29638 |
| 26" | 22.1 HP, 35.6 Torque (lbs.-ft.) | Yes | Gas | Honda® GX690 | Yes | N/A | 5801522 | 34013 |
| 14" | 25 HP-25 GPM @ 2000 PSI | Yes | Hydraulic | Webster® | No | N/A | 5800489 | 48426 |
| 20" | 25 HP-25 GPM @ 2000 PSI | Yes | Hydraulic | Webster® | No | N/A | 5800490 | 48427 |
| 26" | 25 HP-25 GPM @ 2000 PSI | Yes | Hydraulic | Webster® | No | N/A | 5800491 | 48428 |
| 14" | 25 HP, 41.2 Torque (lbs.-ft.) | Yes | Gas | Kohler® Command CH742 | Yes | N/A | 5800597 | 79036 |
| 20" | 25 HP, 41.2 Torque (lbs.-ft.) | Yes | Gas | Kohler® Command CH742 | Yes | N/A | 5800598 | 79037 |
| 26" | 25 HP, 41.2 Torque (lbs.-ft.) | Yes | Gas | Kohler® Command CH742 | Yes | Right Hand | 5800599 | 78816 |
